Allen-Bradley 1738-OB16EM12 ArmorPoint Digital Output Module
No reviews
Sku:1738-OB16EM12
Country Of Origin: USA
Vendor: Allen Bradley
Type: Digital Output
In stock!
100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
Share
Product description
Overview
The 1738-OB16EM12 is a 16-point sourcing digital output module from the ArmorPoint I/O family by Rockwell Automation (Allen-Bradley). It features sealed M12 connectors and an IP67-rated housing, ideal for direct machine mounting in harsh industrial environments.
Technical Specifications
Catalog Number: 1738-OB16EM12
Manufacturer: Rockwell Automation (Allen-Bradley)
Module Type: Digital Output
Number of Channels: 16 (Sourcing Type)
Output Voltage Range: 10–28.8 V DC
Nominal Output Voltage: 24 V DC
Maximum Output Current:
1.0 A per channel
4.0 A total per module
Output ON Voltage Drop: ≤ 0.2 V DC
Leakage Current (OFF): ≤ 0.5 mA
Connector Type: M12 Micro-style (8 × 5-pin)
Power Supply: 24 V DC (via POINTBus)
POINTBus Current: 150 mA @ 5 V DC
Power Dissipation: 3.0 W max
Thermal Dissipation: 10.3 BTU/hr max
Isolation Voltage: 50 V continuous (field to system)
Environmental Rating: IP65 / IP66 / IP67 / IP69K
Operating Temperature: –20°C to +60°C
Storage Temperature: –40°C to +85°C
Dimensions (H × W × D): 120 × 72 × 42 mm
Weight: 290 g
Keyswitch Position: 1
Replacement Category: No planned RA replacement
Functional Highlights
16 non-isolated sourcing digital outputs for discrete control
Rugged, sealed IP67 enclosure for direct machine integration
Built-in LED indicators for output status and diagnostics
Consumes 2 bytes of output data and produces 2 bytes of input data (status)
Compatible with Studio 5000 Add-On Profiles (AOP)
Supports autobaud detection and explicit messaging
No external enclosure required when using IP67-compliant cabling
