The8440-1923HMI panel from Woodward provides advanced monitoring and control for generator management systems. Engineers integrate8440-1923with the easYgen-3200-5 controller series to manage generator synchronization and load distribution.
Furthermore,8440-1923offers an intuitive operator interface with a graphic LCD display and programmable control keys. Operators therefore adjust generator parameters, monitor electrical values, and review alarms directly from the front panel.
Woodward designed8440-1923for industrial generator applications requiring reliable control, fast configuration, and clear visual feedback.
Technical Specifications
Parameter
Specification
Manufacturer
Woodward
Model
8440-1923
Product Type
Generator Controller HMI Panel
Series
easYgen-3200-5
Compatible Controllers
Woodward easYgen-3200 series generator controllers
Primary Function
Operator interface for generator monitoring, configuration, synchronization, and load management
Display Type
Graphical LCD display
Display Resolution
128 × 64 pixels
Display Backlight
LED backlit LCD for clear visibility in industrial environments
User Interface
Multi-function navigation buttons and programmable pushbuttons
Menu Control
Parameter configuration, alarm viewing, generator status monitoring
Power Supply
24 VDC nominal
Input Voltage Range
18 – 32 VDC
Power Consumption
Approximately 5 W during operation
Communication Interfaces
CANbus and Ethernet
CANbus Protocol
CANopen / J1939 compatible communication architecture
CANbus Speed
Up to 1 Mbps
Ethernet Interface
10/100 Mbps industrial Ethernet port
Data Monitoring
Real-time generator voltage, frequency, load, and alarm monitoring
Alarm Indication
Visual alarms through LCD display and status indicators
Mounting Type
Panel-mount installation for generator control cabinets
Front Panel Size
144 mm × 72 mm
Installation Depth
Approx. 55 mm
Cut-out Dimensions
138 mm × 68 mm panel cut-out
Enclosure Material
Industrial grade plastic and metal internal structure
Weight
Approximately 0.3 kg
Operating Temperature Range
–20 °C to +70 °C
Storage Temperature Range
–40 °C to +85 °C
Humidity Range
Up to 95% relative humidity, non-condensing
Protection Level
Suitable for installation inside protected control panels
Application Environment
Generator control panels, power generation stations, distributed energy systems
System Integration
Generator synchronization systems, microgrid controllers, standby power installations
FAQ
Q1: What is the main function of the8440-1923HMI panel? The8440-1923provides a graphical operator interface for the easYgen-3200 generator controller series. Operators monitor generator parameters, adjust settings, and review alarms directly through the LCD display.
Q2: Which controllers work with the8440-1923panel? The8440-1923works with Woodward easYgen-3200 series generator control systems. Engineers commonly integrate this panel with easYgen-3200-5 controllers for synchronization and load management tasks.
Q3: What communication interfaces does the8440-1923support? The8440-1923includes CANbus and Ethernet communication interfaces for industrial network integration. These interfaces allow data exchange between generator controllers, monitoring systems, and power management platforms.
Q4: What power supply does the8440-1923require? The8440-1923operates with a 24 VDC power supply and consumes approximately 5 watts during normal operation. This voltage specification matches most generator control cabinet power systems.
Q5: Is the8440-1923available in stock? Yes. We supply8440-1923units asbrand-new original factory productswith reliable industrial quality. Our warehouse keeps inventory available and we usually ship within3 days to 2 weeks depending on order size.
Installation Notes
Install within Woodward control racks or cabinets
Connect directly to magnetic pickup sensors near turbine or engine shafts
Use proper wiring and shielding to prevent electrical noise interference
Calibration and verification of MPU signals may be required during commissioning
