3BSE008105R1 | ABB SC560 SC560 Submodule Carrier incl local CPU
No reviews
Sku:SC560
Country Of Origin: Sweden
Vendor: ABB
Type: Submodule Carrier
In stock!
100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
Share
Product description
Overview
The ABB SC560 (Part Number: 3BSE008105R1) is a submodule carrier with an integrated CPU, designed for high-density I/O configurations in industrial automation systems. It plays a vital role in signal processing, real-time monitoring, and communication within ABB’s control platforms such as Advant Controller 450RMC and AC 800M.
Specifications
Product Type: Communication Module / Submodule Carrier
Integrated CPU: 32-bit RISC processor @ 800 MHz
Memory: 64 MB DDR3 RAM with ECC
Input Voltage: 24 V DC (±30%)
I/O Channels:
16 digital inputs (24 V DC, opto-isolated)
16 digital outputs (24 V DC, relay-isolated)
Switching Capacity: 2 A per output (resistive load)
Communication Interface: RS-485 serial port
Hot-Swappable: Yes
Diagnostics: Real-time signal monitoring and fault detection
Mechanical & Environmental
Dimensions: 486 mm × 288 mm × 27 mm
Weight: 0.76 kg
Operating Temperature: –40°C to +70°C
Storage Temperature: –40°C to +85°C
Shock Resistance: 50G (11 ms)
Protection Rating: IP20
RoHS Status: Exempt (per EU Directive 2011/65/EU)
WEEE Category: Small Equipment (no external dimension >50 cm)
Highlights
High signal isolation for noise immunity
Modular design for easy installation and replacement
Hot-swapping support for minimal downtime
Compatible with ABB 800xA and other control systems
