The396604-03-0analog input module delivers accurate signal acquisition for ControlWave automation systems. It converts field voltage and current signals into precise digital values for control logic execution. Engineers integrate this module into remote telemetry and process monitoring installations. Moreover, the compact structure simplifies panel layout while maintaining industrial durability.
The396604-03-0works seamlessly within Emerson ControlWave and Bristol Babcock platforms. It supports demanding oil, gas, and utility applications requiring stable signal integrity. Therefore, system designers achieve consistent measurement performance in distributed environments.
Specifications
Parameter Category
Specification Detail
Manufacturer
Emerson
Product Model
396604-03-0
Product Type
Analog Input Module
Compatible Series
ControlWave / Bristol Babcock systems
Input Channels
8 differential analog input channels
Supported Signal Types
4–20 mA current, 0–5 VDC, 0–10 VDC
Input Resolution
16-bit A/D conversion
Input Impedance
>250 kΩ voltage input impedance
Measurement Accuracy
±0.1% of full scale at 25°C
Sampling Rate
Up to 10 samples per second per channel
Signal Isolation
Channel-to-channel and system isolation
Communication Interface
Backplane bus connection to CPU module
Status Indicators
LED indicators for power and channel activity
Operating Voltage
12–30 VDC supplied through backplane
Power Consumption
<5 Watts typical
Energy Storage
Onboard filtering capacitors for signal stabilization
Mounting Type
Chassis-mounted within ControlWave enclosure
Dimensions (Approx.)
165 mm × 130 mm × 40 mm
Weight (Approx.)
0.45 kg
Operating Temperature
–40°C to +70°C
Storage Temperature
–40°C to +85°C
Relative Humidity
5–95% non-condensing
Application Areas
Flow measurement, pressure monitoring, remote RTU systems
FAQ
Q1: How many input channels does the 396604-03-0 provide? The396604-03-0provides eight differential analog input channels for flexible signal acquisition.
Q2: What signal types does the 396604-03-0 support? It supports 4–20 mA current and 0–5 VDC or 0–10 VDC voltage inputs.
Q3: What resolution ensures measurement accuracy? The396604-03-0uses 16-bit A/D conversion for precise industrial monitoring.
Q4: Do you provide original factory units in stock? Yes, we supply brand-new original factory products with ready inventory.
Q5: What shipping and return policies apply? We ship within 3 days to 2 weeks, and we support 30-day returns for quality concerns.
Installation Notes
Install in the designated slot within the Ovation I/O chassis
Ensure proper wiring to actuator and feedback device terminals
Verify excitation frequency and feedback polarity before commissioning
Follow Emerson grounding and shielding procedures
Handle using ESD-safe practices and store in anti-static packaging
