Product description
Overview
The Bently Nevada 330103-00-07-50-02-05 is a reverse mount proximity probe used in the 3300 XL Proximity Transducer System, which includes the probe, extension cable, and Proximitor® sensor. It utilizes eddy current technology to measure the distance between the probe tip and a conductive surface, enabling non-contact monitoring of shaft vibration and axial displacement.
Configuration Breakdown
330103: Probe series: 3300 XL 8 mm (reverse mount)
00: Unthreaded length: 0.0 inch
07: Case length: 0.7 inch (≈17.8 mm)
50: Cable length: 5.0 meters (≈16.4 feet)
02: Connector: Miniature coaxial ClickLoc™
05: Cable type: Standard non-armored
Technical Specifications
Tip Diameter: 8 mm
Mounting Thread: 3/8-24 UNF (reverse mount)
Measurement Range: 0.25 mm to 2.3 mm (10 to 90 mils)
Sensitivity: 200 mV/mil ±5%
Output Voltage: –1 to –24 VDC
Operating Temperature: –51°C to +177°C
Material: AISI 303/304 stainless steel body, PPS tip
Environmental Rating: IP67, sealed with Viton® O-ring
Weight: 0.323 kg
Country of Origin: United States
Installation Notes
Must be paired with a 3300 XL extension cable and Proximitor® sensor
Reverse mount requires access from behind the mounting surface
Set initial gap to achieve –9 VDC output for calibration
Maintain minimum bend radius for cable; avoid sharp bends
Use connector protectors or silicone tape for sealing in harsh environments
