The Woodward 5503-302D is an advanced industrial controller module designed for precise engine and machinery regulation. It provides reliable control of mechanical and electronic actuators in demanding industrial environments. Moreover, its compact design allows seamless integration into existing automation systems. Engineers rely on 5503-302D for high-speed signal processing and consistent operational accuracy.
Technical Specifications
Parameter Category
Specification Details
Manufacturer
Woodward
Model Number
5503-302D
Module Type
Controller Module
Control Functions
Position, Speed, and Torque Control
Input Signals
±10 V analog or digital command signals
Output Signals
0.5–5 A per channel, configurable for actuator control
Power Supply
24 V DC nominal, 18–32 V DC operating range
Response Time
Typically <5 ms from input command to actuator output
Control Loop Bandwidth
Up to 200 Hz
Feedback Compatibility
Resolver, potentiometer, or encoder inputs
Mounting
Panel mount or DIN rail adaptable
Dimensions (L×W×H)
170 mm × 110 mm × 70 mm
Weight
Approx. 1.4 kg
Housing Protection
IP65 rated for dust and moisture protection
Operating Temperature
-40°C to +70°C
Storage Temperature
-55°C to +85°C
Diagnostics
LED status for power, command, and fault detection
Energy Storage
Internal capacitor for transient stability
Compliance
CE and UL recognized for industrial applications
FAQ
Q1: Is the Woodward 5503-302D brand new and original? A1: Yes,5503-302Dis 100% new, original, and factory-sealed by Woodward.
Q2: How quickly can the module be shipped? A2: Shipping is typically within 3 days to 2 weeks, depending on order quantity and logistics.
Q3: Can it integrate with existing hydraulic or electric actuators? A3: Yes,5503-302Dsupports standard analog and digital feedback for seamless integration.
Q4: What industries commonly use this controller? A4: Common industries include power generation, manufacturing machinery, turbines, and industrial engines.
Q5: Is there a warranty or return policy? A5: Yes, verified quality issues allow returns within 30 days according to Woodward’s policy.
Installation Notes
Install within Woodward control racks or cabinets
Connect directly to magnetic pickup sensors near turbine or engine shafts
Use proper wiring and shielding to prevent electrical noise interference
Calibration and verification of MPU signals may be required during commissioning
